Technical Overview
Frameset
Frame:
Roadmachine 01 Premium Carbon with Tuned Compliance Concept Endurance | ICS Technology Stealth Cable Routing | Integrated Downtube Storage | Stealth Dropout Design | 12 x 142mm Thru-Axle
Fork:
Roadmachine 01 Premium Carbon with Tuned Compliance Concept Endurance | Flat Steerer Fork | Stealth Dropout Design | Internal Cable Routing | Flat Mount Disc | 12 x 100mm Thru-Axle
Cockpit
Handlebar:
ICS Carbon Evo | One Piece Full Carbon Cockpit | 127mm drop, 70mm reach, 8° flare
Seat
Seatpost:
Roadmachine 01 Premium Carbon D-Shaped Seatpost | 15mm Offset | D-Fender Compatible
Saddle:
Fizik Argo Tempo R1 | 150mm
Drivetrain
Crankset:
SRAM Red AXS
Chainrings:
46-33T
Power Meter:
SRAM Red AXS Power Meter
Cassette:
SRAM Red (XG-1290)
Cassette Size:
10-33T
Chain:
SRAM RED
Front Derailleur:
SRAM RED AXS
Rear Derailleur:
SRAM Red AXS
Shifters:
SRAM Red AXS (ED-RED-E1)
Gears:
2 x 12
Bottom Bracket:
PF86 Bottom Bracket
Brakes
Brake Levers / Calipers:
SRAM Red AXS (ED-RED-E1)
Rotors:
SRAM Paceline X | Centerlock
Rotor Size (F/R):
160 / 160mm
Wheels
Rims:
Zipp 303 Firecrest Tubeless Disc
Hubs (F/R):
Zipp ZR1 DB
Tires:
Vittoria Corsa N.EXT G2.0 | TLR (Tubeless Ready) | 30mm
Tubeless Information:
Tubeless Only Rims | Tubeless Tires
Accessories
In the Box:
Integrated Rear Light 20 StVZO | Roadmachine Bottle Cages | Storage Pouch
Additional Information
Tire Clearance:
up to "40mm measured" (frameset clearance) but limited to "36mm measured" by the front derailleur
Weight without Pedals:
7.2 Kg
ASTM Classification:
Level 2
System Weight Limit:
110kg
