Technical Overview
Frameset
Frame:
Speedfox Premium Aluminium with APS Suspension System with 120mm | Internal Cable Routing | Post Mount Disc | 12 x 148mm Boost Thru-Axle
Fork:
Suspension
Front Suspension:
RockShox Recon Silver RL | 130mm
Rear Suspension:
Fox Float DPS | Performance | EVOL
Remote Lockout:
Cockpit
Stem:
BMC AMSM 02
Handlebar:
BMC MFB 03 Alloy | 760mm
Grips:
Seat
Seatpost:
X-Fusion Manic Dropper | 125 / 150mm | 31.6mm
Saddle:
WTB Silverado Comp
Drivetrain
Crankset:
SRAM Stylo 6k Eagle
Chainrings:
30T
Cassette:
SRAM NX Eagle
Cassette Size:
11-50T
Chain:
SRAM NX Eagle
Rear Derailleur:
SRAM NX Eagle
Shifters:
SRAM NX Eagle
Gears:
1 x 12
Bottom Bracket:
BSA Threaded Bottom Bracket
Brakes
Brake Levers / Calipers:
SHIMANO BL-M6100 Levers | BR-M6100 Calipers
Rotors:
SHIMANO SM-RT54
Rotor Size (F/R):
160 / 160 S-M | 180 / 160 L-XL
Wheels
Rims:
Alex MD30 | 30mm Inner Width
Hubs (F/R):
SHIMANO HB-MT400-B | FH-MT400-B
Tires:
Maxxis Forekaster 29 x 2.35 | EXO TR
Additional Information
Tire Clearance:
58mm
Weight without Pedals:
ASTM Classification:
Level 4
System Weight Limit:
120kg
General Product Safety Regulation (GPSR):
Safety Instructions GPSR (EU)
Responsible person according to GPSR (EU)
| Size | S | M | L | XL |
|---|---|---|---|---|
| Rider Height | <172 | 172-182 | 180-188 | >188 |
| Reach | 408 | 430 | 450 | 465 |
| Stack | 600 | 610 | 620 | 635 |
| Bar Rise | 15 | 15 | 15 | 15 |
| Bar Sweep | 9 | 9 | 9 | 9 |
| Bar Width | 750 | 750 | 750 | 750 |
| BB Drop | 37 | 37 | 37 | 37 |
| Crank Length | 170 | 175 | 175 | 175 |
| Fork Length | 526 | 526 | 526 | 526 |
| Fork Rake | 51 | 51 | 51 | 51 |
| Front Center | 677 | 704 | 728 | 748 |
| Head Tube | 95 | 105 | 115 | 135 |
| Head Tube Angle | 68 | 68 | 68 | 68 |
| Rear Center | 445 | 445 | 445 | 445 |
| Saddle Height Range | 645-770 | |||
| Seat Angle | 73.8 | 73.8 | 73.8 | 73.8 |
| Seat Tube | 420 | 440 | 480 | 510 |
| Seatpost Drop | 125 | 150 | 150 | 150 |
| Seatpost Length | 377 | 447 | 447 | 447 |
| Standover Height | 713 | 734 | 752 | 773 |
| Stem Angle | ±5 | ±5 | ±5 | ±5 |
| Stem Length | 45 | 45 | 55 | 55 |
| Top Tube | 587 | 611 | 634 | 653 |
| Trail | 90 | 90 | 90 | 90 |
| Wheelbase | 1123 | 1145 | 1169 | 1189 |
