Technical Overview
Frameset
Frame:
Teammachine SLR 01 Premium Carbon with Aerocore Design | ICS Technology Stealth Cable Routing | Stealth Dropout Design | TCC Race Compliance Level | Flat Mount Disc | 12 x 142mm Thru-Axle
Fork:
Teammachine SLR 01 Premium Carbon | ICS Technology Stealth Cable Routing | TCC Race Compliance Level | Stealth Dropout Design | Flat Mount Disc | 12 x 100mm Thru-Axle
Cockpit
Handlebar:
ICS Carbon Evo | One Piece Full Carbon Cockpit | 127mm drop, 70mm reach, 8° flarer
Seat
Seatpost:
Teammachine SLR 01 Premium Carbon D-Shaped Seatpost | 15mm Offset
Saddle:
Fizik Vento Argo R1 | 140mm
Drivetrain
Crankset:
SRAM Red AXS
Chainrings:
48-35T
Power Meter:
SRAM Red AXS Power Meter
Cassette:
SRAM Red (XG-1290)
Cassette Size:
10-28T
Chain:
SRAM RED
Front Derailleur:
SRAM RED eTap AXS
Rear Derailleur:
SRAM Red eTap AXS
Shifters:
SRAM Red eTap AXS
Gears:
2 x 12
Bottom Bracket:
PF86 Bottom Bracket
Brakes
Brake Levers / Calipers:
SRAM Red eTap AXS
Rotors:
SRAM Centerline XR | Centerlock
Rotor Size (F/R):
160 / 160mm
Wheels
Rims:
Zipp 353 NSW Tubeless Disc
Hubs (F/R):
Zipp Cognition V2 | Axial Clutch V2™
Tires:
Pirelli P-Zero Race SL TLR | 28mm
Tubeless Information:
Tubeless Ready Rims | Tubetype Tires
Accessories
In the Box:
Aerocore Bottle Cages
Additional Information
Tire Clearance:
30mm measured tire
Weight without Pedals:
6.7 Kg
ASTM Classification:
Level 1
System Weight Limit:
110kg
